Flush-mounted external roller blinds

SP and SP-E roller blind systems match the building facade while remaining truly invisible. Thus, the building retains its original look.
All elements of the system, such as e.g. the revision cover and guiding rails may be matched to the window colour.
External roller blind profiles are made of top quality aluminium profiles. The profiles are filled with foam, ensuring excellent thermal insulation and soundproofing.
Extruded profiles of external roller blinds are highly resistant to friction, weather conditions and are characterised by their long life. They are available in all colours of the RAL palette.
The SP and SP-E systems do not interfere with neighbouring window or door structures. They are fully integrated with the building facade, thus ensuring the optimal energy balance of the building.
Available actuators and accessories: lanyard or string winding mechanism; crank winder for lanyards or strings – crank bar; electric actuator; button and key switches – clock switch; remote controls

Technical parameters

Roller blind profile

Polyurethane-filled aluminium profile or PVC profile (PT)

Roller blind profile dimensions
(height in mm)

PA 37 | PA 39 | PA 40 | PA 45 | PA 52 | PA 55 | PT 37 | PT 52

Roller blind profile dimensions
(width in mm)

8,5 | 9 | 8,7 | 9 | 13 | 14 | 8 | 14

Roller blind profile surface

Double-coated (PU/PA system) or plastic coating

Colours

According to the colour palette / non-standard colours available on request - all RAL palette colours are available

Box

styrofoam

Actuation

A crank winding mechanism for a string / tape / cranks / electric actuators with or without timer / remote control / installation connector and key switch

Mosquito net

Unavailable

Application

New buildings

Heat transfer coefficient

Down to 0.54 W/m²K
